System Architecture:
|
Processor:
|
Marvell XScale PXA300 624 MHz
|
Operating System:
|
Microsoft® Windows CE 5.0
|
Memory:
|
128 MB RAM X 128 MB Flash
|
Display:
|
3.5 in. transreflective active matrix 65k color LCD with backlight, QVGA (240 x 320)
|
|
|
Keypad: 28 key numeric with shifted alpha and backlit keys
52 key full alphanumeric with backlit keys
|
Audio:
|
Built-in microphone and speaker, stereo headset jack
|
I/O Ports:
|
Full speed USB 1.1 from cradle (or I/O cable); RS232 (115Kbps) from cradle
|
Application Software:
|
Honeywell Powertools® and Demos
|
Battery:
|
Li-Ion 3.7 V, 3300 mAh (12.2 Wh)
|
Expected hours of operation:
|
12 hours
|
Expected charge time:
|
Less than 6 hours
|
Imager/Scanner:
|
5300SR 2D imager with Adaptus 5.0 Technology and laser aimer
|
Decode Capabilities:
|
2D:
|
Data Matrix (EC 000, 050, 080, 100, 140, 200), QR Code, PDF417, MicroPDF417, MaxiCode, Aztec, Aztec Mesas, Code 49, EAN-UCC Composite
|
Linear:
|
Code 39, Code 128, Codabar, I-2 of 5, UPC, and most other popular codes
|
Postal:
|
Postnet, Planet Code, British Post, Canadian Post, Japanese Post, KIX (Netherlands)
|
|
|
Wireless Connectivity:
|
WLAN:
|
Dual Mode 802.11 b/g (11Mbps/54 Mbps) with internal atenna
|
WLAN Security:
|
Wi-Fi certified, 802.1x, WPA2, EAP, WEP, LEAP, TKIP, MD5 EAP-TLS, WPAPSK, PEAP,CCXv4
|
WPAN:
|
Bluetooth® Class II (10 m) v2.0 Enhanced Data Rate (EDR) with on-board antenna. BQB certified
|
|
