Technical data
|
Max print width:
|
ttPRINT ML 53: 53 mm
ttPRINT ML 107: 107 mm
ttPRINT ML 128: 128 mm
|
Print lengths:
|
140 mm, 240 mm, 340 mm, 447 mm, 570 mm, 630 mm
|
Resolution:
|
300 dpi
|
Print speed:
|
ttPRINT ML 53: up to 450 mm/s
ttPRINT ML 107: up to 450 mm/s
ttPRINT ML 128: up to 400 mm/s
|
Return speed:
|
ttPRINT ML 53: up to 500 mm/s
ttPRINT ML 107: up to 500 mm/s
ttPRINT ML 128: up to 400 mm/s
|
Barcodes:
|
|
1D-Codes:
|
EAN 8, EAN 13, EAN 128, EAN ADD ON, UPC-A, UPC-E, Code 39, Code 39 ext., Code 93, Code 128A, Code 128B, Code 2/5 interleaved, ITF 14, ITF 16, CODABAR, Pharmacode, PZN Code, Identcode / German Post Code.
|
|
2D-Codes:
|
PDF417, MAXICODE, DataMatrix, CODABLOCK F, QR Code.
|
|
Composite Codes:
|
GS1 DataBar Expanded, GS1 DataBar Limited, GS1 DataBar Omnidirectional, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Truncated - Further Codes on request
|
|
Interfaces:
|
Serial: RS-232, RS-422 *, RS-485 *
Parallel: Centronics
USB: 1.1
Ethernet / LAN: Internet 10/100 Base-T *
* - option
|
Thermal ribbon:
|
Max. length: 600 m (ø 85 mm), colour outside.
|
Electrical connections:
|
Voltage supply: 230 V / 50 Hz; optional 115 V / 60 Hz.
Power consumption: max. 380 VA.
Compressed air: 6 bar, dry and oil-free.
|
Operating conditions:
|
Temperature: 5° - 45°C
Relative humidity: max. 80 % (non-condensing).
|
|
